Heat treatment is a controlled process of heating, soaking, and cooling metals in a specific medium to alter their internal microstructure, thereby enhancing their mechanical, physical, and chemical properties. Crucially, it changes the metal's internal structure without altering its shape or overall chemical composition.
For aluminum die casting and zinc die casting, heat treatment is a vital step for performance customization. It allows manufacturers to tailor the properties of aluminum die cast parts to meet the stringent demands of industries like automotive, aerospace, and electronics.
Aluminum alloys can undergo various heat treatment processes, each designed for specific outcomes:
1. T1 - Artificial Aging
Applied to parts that cool rapidly after casting (like die castings). It improves strength, hardness, and machinability. Typical parameters: 150–180°C for 1–24 hours.
2. T2 - Annealing
Used primarily to relieve internal stress from casting or machining, improving dimensional stability and ductility. Typical parameters: 280–300°C for 2–4 hours.
3. T4 - Solution Heat Treatment + Natural Aging
Involves solution treatment followed by natural aging. It enhances overall mechanical properties, particularly ductility and corrosion resistance at room temperature. Common for Al-Mg series alloys.
4. T5 - Solution Treatment + Incomplete Artificial Aging
A low-temperature, short-duration aging process after solution treatment. It significantly increases strength and hardness and is suitable for structural components where very high toughness is not the primary concern.
5. T6 Heat Treatment - Solution Treatment + Full Artificial Aging
T6 heat treatment is the most common method for strengthening aluminum die castings. The process involves solution treatment at high temperatures, rapid quenching, and then aging at elevated temperatures (typically 175–185°C) for an extended period (5+ hours). This achieves the highest tensile strength and hardness, though some ductility is reduced. T6 temper aluminum is essential for high-stress components like engine brackets and housings. The question "Can die cast aluminum be T6 tempered?" is common, and the answer is yes, with proper alloy selection and process control.
6. T7 - Stabilization Treatment
A high-temperature aging process that improves dimensional stability and corrosion resistance, ideal for parts operating in high-temperature environments.
7. T8 - Solution Treatment + Overaging
Performed at even higher temperatures than T7 to achieve high ductility and stability, often used before assembly or further forming.
8. T9 - Cold & Hot Cycle Treatment
A stress-relieving process using thermal cycling to eliminate internal stresses and stabilize dimensions, critical for high-precision castings.
The answer is yes, but it depends heavily on the specific alloy composition and the part's design.
Traditional aluminum die casting alloys like A380 or ADC12 (Al-Si systems) have excellent fluidity for casting but can present challenges for T6 due to their higher silicon content. However, with modern process control and suitable alloys (e.g., ones with magnesium and copper additions), successful T6 treatment for aluminum castings is achievable and widely practiced.
It's critical to note that die cast parts can contain micro-porosity. High-temperature solution treatment can sometimes cause these pores to expand, leading to surface blistering or reduced mechanical properties. Therefore, high-pressure die casting processes that yield low-porosity, high-integrity die casting are best suited for subsequent heat treatment. This is a key consideration when choosing a knowledgeable aluminum die casting company.
Beyond T6, other vital aluminum heat treatment processes include:
· Annealing (T2): For stress relief and improving machinability.
· Solution Treatment (T4): The foundational step for creating a supersaturated solid solution, preparing the alloy for aging.
· Aging (T5/T6/T7): The controlled precipitation process that increases strength and hardness.
· Stabilization (T7): Enhances performance in high-temperature applications.
1. Enhanced Mechanical Properties: Significantly increases tensile strength, yield strength, and hardness.
2. Internal Stress Relief: Eliminates stresses locked in from the rapid cooling of the die casting process, preventing distortion and cracking.
3. Improved Corrosion Resistance: Processes like T7 enhance the alloy's ability to resist corrosion.
4. Better Machinability: Annealing softens the material, making it easier to machine.
5. Dimensional Stability: Stabilizes the microstructure, ensuring the part maintains its shape and size under load and over time—a critical factor for precision die casting components.
Choose EDT Diecasting: Your Partner for High-Performance Zinc and Aluminum Die Castings
When you need a reliable and technically proficient die casting manufacturer, EDT Diecasting Technology (Suzhou) Co., Ltd. is your ideal partner.
As a specialist in zinc and aluminum die casting, we leverage advanced European die casting technology to deliver high-quality, high-pressure die casting solutions. Our facility is equipped with state-of-the-art melting, casting, machining, and inspection equipment, ensuring rigorous quality control at every stage. We specialize in producing high-integrity die casting with excellent dimensional stability.
Whether you require complex precision die castings, thin-wall enclosures, or structural components that require T6 temper or other heat treatment services, EDT has the expertise to provide a reliable custom die casting solution. We understand the critical relationship between die casting design, alloy selection, and post-casting treatments to meet the demanding specifications of the automotive, aerospace, and electronics industries.
Choose EDT Diecasting for quality, precision, and trust. Contact us today to discuss your project and discover how our die casting services can provide the solution you need.
